An overview of InterDigital's M2M/IoT Standardized Service Delivery Platform from MWC 2013.

21 December 2012
Machine to Machine (M2m) / Internet of Things (IoT)
Service Layer

‹#›
InterDigital Confidential and Proprietary – Subject to NDA, dated ___
© 2012 InterDigital, Inc. All rights reserved.
Billions of ever-increasing “Things” are to be connected to the Internet to enable
people’s smart life via smart cities,
smart transportation,
smart environment
smart shopping
smart health,
smart home,
etc.
Segmented
various vertical
applications with
proprietary solutions which increase roll-out cost
and speed and hinder mass-adoption
M2M/IoT – Big “V” (Volume/Variety/… )
People
Thing
2020
2015
2010
2005
25 Billion
50 Billion







Big “V”  Big “Challenge”  Big “Smart”
‹#›
InterDigital Confidential and Proprietary – Subject to NDA, dated ___
© 2012 InterDigital, Inc. All rights reserved.
Smart Energy/ Connected Home

Bluetooth
WiFi
Cellular
ZigBee
Zwave
RFID
Healthcare

Intelligent Highways & Vehicular Comms

Retail


Security & Surveillance
Metering
DSRC
Appliance Control
Home Entertainment
Point of Sale
Tele-Vending
Infotainment
Toll Collection
Wellness
Health Monitoring
Safety Sensors
Some Applications & the Likely Technologies
They will Use

NFC
PLC
‹#›
InterDigital Confidential and Proprietary – Subject to NDA, dated ___
© 2012 InterDigital, Inc. All rights reserved.
Not All Devices are Created Equal!
Constrained devices with low footprint: limitations in size, processing horsepower, memory, storage, bandwidth capability
Devices with long lifetimes (years)
Unmanned devices => plug-n-play installation, self-organization, device management requirements, security threats
Unwired, un-chargeable devices => very low power consumption often a critical requirement
Mobility requirements ranging from fixed -> pedestrian -> vehicular
High delay sensitivity, reliability for mission-critical applications
Requirements Unique to M2M…

Feature & Smart Phones, Notebooks, Tablets, Media Players…
PCs, Servers, Routers, Gateways, Printers, Gaming Equipment
Transportation, Navigation, Mobile Healthcare
Buildings, Industrial, Retail, vending, Power
Sensors, Meters, Controllers, Microprocessors…
Source: Harbor Research
‹#›
InterDigital Confidential and Proprietary – Subject to NDA, dated ___
© 2012 InterDigital, Inc. All rights reserved.
SmartEnergy
Healthcare
Transportation
Retail
Security & Surveillance
Low Power Consumption
High Data Rate
Mobility
DelaySensitivity
LocationTracking
Long ReplacementCycle
PersistentService
And Not All Applications are Created Equal!
Requirements Vary Widely Based on Use Case
Critical Importance
Medium Importance
‹#›
InterDigital Confidential and Proprietary – Subject to NDA, dated ___
© 2012 InterDigital, Inc. All rights reserved.

The Intersection of Communications Networks
With a variety of Industry Segments
Each with its own unique Requirements

A Smorgasbord of Applications with Diverse Requirements

Source: Harbor Research
Forecast by Segment for 2013
‹#›
InterDigital Confidential and Proprietary – Subject to NDA, dated ___
© 2012 InterDigital, Inc. All rights reserved.
M2M Enabling Technologies
‹#›
InterDigital Confidential and Proprietary – Subject to NDA, dated ___
© 2012 InterDigital, Inc. All rights reserved.
Embedded Devices and Sensing: Resource-constrained computation and communications
Communications: Energy-efficient short-range communications and sensor networks
IPv4/IPv6: Naming, addressing, routing
Data and Information Process: Semantic sensor data modeling
Web Technologies: RESTful operations, real-time web
Services & Applications: Semantic services, etc

To enable the M2M services, a couple of technologies across different layers are needed.
The embedded devices should be able to accurately sense the event/status and send the data out.


7
M2M/IoT Standardization – Protocol Stack
3GPP/3GPP2 MTC
oneM2M (ARIB, ATIS, CCSA, ETSI, TIA, TTA, and TTC)
(Common Service Layer: Provide M2M Service Capabilities)
(Potentially evolve to IoT service)
Control and Management
Transport
Layer
Network
Layer
IEEE 802.11/15
3GPP/3GPP2 RAN
IEEE PLC
PHY/MAC
Layer
IETF CoAP/HTTP
IETF ROLL/6LoWPAN
Smart Profiles
(SE 2.0, HealthCare, Home Automation)
EPCglobal Standards for RFID
W3C (World Wide Web Consortium)
(HTML 5.0, RDF, OWL)
IETF TCP/UDP/SCTP
App
Protocol
Layer
Service
Layer
Higher
Layer
‹#›
InterDigital Confidential and Proprietary – Subject to NDA, dated ___
© 2012 InterDigital, Inc. All rights reserved.
M2M - Existing Deployments
RFID
Proprietary Service Function Set
B
Proprietary Application Logic Set
B
GPS, Cellular
Proprietary Service Function Set
C
Proprietary Application Logic Set
C
WiFi, BT, WSN
Proprietary Service Function Set
D
Proprietary Application Logic Set
D
Application Logic
Proprietary Service Functions
Communications
Infrastructure
Smart City in Oulu
RFID
Proprietary Service Function Set
A
Proprietary Application Logic Set
A



Vertical and Proprietary Solution
‹#›
InterDigital Confidential and Proprietary – Subject to NDA, dated ___
© 2012 InterDigital, Inc. All rights reserved.
Talk point:
Current solutions are proprietary and vertical

Focus only one use case
People from the North should be very familiar with E-Zpass which is a road toll system.
Literally, we put a RFID on our vehicles so that the receiver depolyed on the road can record our entering and leaving the highway, so that to generate charging information. For different applications, the proprietary service function sets are quite different, which only serves a certain kind of application.

The OnStar is the in vehicle navigation/communicaiton system.
Oulu Smart city is a wireless infrastructure testbed deployed in Finland.

All these deployments Kind of isolated, not efficient
9
M2M/IoT – Common Service Layer
Common Service Layer
Network & Application-agnostic, but aware
Easy to integrate different vertical applications
Expedite application development
Decrease roll-out cost and speedup deployment
Interoperability
Scalability
Application
A
Wireless/Wireline/Hybrid Network 1
Common Service Layer
Open Middleware Platform
Application Logic
Common
Service Functions
Communication
Infrastructure
Application
B
Application
C
Application
D
Wireless/Wireline/Hybrid Network 2
Horizontal Solution
& Mass-Adoption

‹#›
InterDigital Confidential and Proprietary – Subject to NDA, dated ___
© 2012 InterDigital, Inc. All rights reserved.
ETSI M2M Service Architecture
M2M Device Domain
M2M Network Domain

‹#›
InterDigital Confidential and Proprietary – Subject to NDA, dated ___
© 2012 InterDigital, Inc. All rights reserved.
Talk points – emphasize its major features to be talked in the following slides
-> IP-based E2E
-> RESTful – resource structure tree
-> Service and Application Registration
-> Resource Announcement/Discovery
-> Resource Subscription/Notification
-> Device Management
-> Interworking


11
ETSI M2M Service Architecture
ETSI-defined protocols to enable M2M service capabilities (e.g. device registration, service discovery, etc);
Core service capabilities available to multiple applications via standardized APIs;
Network-agnostic protocol, with bindings possible to HTTP and CoAP;
Allows application access to Service Platform and Device, as well as local application control on Gateway;
M2M Service Capabilities Layer (DSCL)
Transport & Routing Layers
Core/ Access Network Layers
M2M Device
M2M Service Capabilities Layer (GSCL)
Transport & Routing Layers
Core/ Access Network Layers
Service APIs
M2M Gateway
M2M Service Capabilities Layer (NSCL)
Transport & Routing Layers
Core/ Access Network Layers
M2M Service Platform
Architecture Standardizes an Access Aware But Agnostic M2M Service Layer Architecture
CoAP/HTTP
CoAP/HTTP
CoAP/HTTP
Binding
‹#›
InterDigital Confidential and Proprietary – Subject to NDA, dated ___
© 2012 InterDigital, Inc. All rights reserved.
ETSI M2M – RESTful Resource Tree
M2M Gateway
M2M Server


M2M Application
M2M Application
M2M Application
M2M Application
eHealth / mHealth
(Bluetooth / ZigBee…)
Smart Energy
(WiFi / ZigBee / …)

Home Automation
(ZigBee / Bluetooth / …)

M2M Area Network 1
M2M Area Network 2
M2M Area Network N


M2M Device
M2M Applications
M2M Applications
M2M Applications
M2M Applications

M2M Applications
M2M Service Provider Applications

‹#›
InterDigital Confidential and Proprietary – Subject to NDA, dated ___
© 2012 InterDigital, Inc. All rights reserved.
Talk points:

Hierarchical tree in D/G/NSCL following “Collection/Element” pattern (such as “applications/”) Under applications, there are different application instances
Mention Resource (De-)Announcement and Resource Discovery – both are important feature for resource operation Resource announcement make the resource visible to other M2M entities.
Mention “accessRights” to provide resource-level access control-based security
Mention “groups” and “subscriptions” for group operation and resource subscription
Mention D’ as a kind of application does not have local resource, but have remote resources on GW

In ETSI M2M, all data/event/information is stored and logically organized as resource.
13
Integration of 3GPP MTC and ETSI M2M

‹#›
InterDigital Confidential and Proprietary – Subject to NDA, dated ___
© 2012 InterDigital, Inc. All rights reserved.
Talk points:

How to integrate 3GPP MTC and ETSI M2M
M2M Server: ETSI M2M Server Service Capabilities + 3GPP MTC SCS
UE: MTC functionalities + M2M Device Service Capabilities
ETSI M2M Reference Points are different from 3GPP Interface
3GPP interface: within one-hop
ETSI reference point: span multiple 3GPP interfaces
14

3GPP MTC Architecture
Tsp: Reference point used by a SCS to communicate with the MTC-IWF related control plane signaling

MTC-IWF: hides the internal PLMN topology and relays or translates signaling protocols used over MTCsp to invoke specific functionality in the PLMN
Supports device trigger functionality
Selection of the most efficient and effective device trigger delivery mechanism and shielding this detail from SCS
Generation of device trigger CDRs
Perform protocol translation
Diameter-based
IP-based
IP-based
‹#›
InterDigital Confidential and Proprietary – Subject to NDA, dated ___
© 2012 InterDigital, Inc. All rights reserved.
InterDigital’s M2M Software Development Platform

‹#›
InterDigital Confidential and Proprietary – Subject to NDA, dated ___
© 2012 InterDigital, Inc. All rights reserved.
16
InterDigital’s M2M Software Development Platform
Web-based Customizable SDK
Interworking with Legacy M2M
Lightweight Device Management
Automated Service Discovery




‹#›
InterDigital Confidential and Proprietary – Subject to NDA, dated ___
© 2012 InterDigital, Inc. All rights reserved.
What the Internet of Things Entails…
Smart Energy
Connected Home
Industrial
Healthcare
Retail
Transportation
Security
IT & Network Infrastructure
Access NW
Access NW
Access NW

Services - Internet/ Web of Things
Network Connectivity
Devices & Objects
M2M Verticals
A Diversity of Applications
Interacting With a Myriad of Device Types
Via The Web and Multiple Heterogeneous Networks
Big Data Analysis
Service Discovery
Semantic Data Modeling
Data Fusion
‹#›
InterDigital Confidential and Proprietary – Subject to NDA, dated ___
© 2012 InterDigital, Inc. All rights reserved.
M2M Evolution to IoT
Current M2M
Connectivity: connection for machines;
Content: massive raw data from things;

Evolution to IoT
Cloud: cloud service and XaaS for IoT;
Context: context-aware design;
Collaboration: collaborative services;
Cognition: semantics and autonomous system adjustment
M2M Service Platform  IoT Service Platform with C6 Capabilities
Wisdom
Knowledge
Information
Data
C6-Enabled Smart IOT

IoT C6 Cube

M2M is communication among machines to manipulate content/data
IoT is communication to/from things which offer new services
via cloud/context/collaboration/cognition technologies

‹#›
InterDigital Confidential and Proprietary – Subject to NDA, dated ___
© 2012 InterDigital, Inc. All rights reserved.
M2M Evolution to IoT – Architecture

‹#›
InterDigital Confidential and Proprietary – Subject to NDA, dated ___
© 2012 InterDigital, Inc. All rights reserved.
Talk points:

Each M2M/IoT Service Capability can be a virtual machine (VM) in the cloud
Cross-VM and cross-cloud collaboration are possible
20
“attribute”



scls

applications

containers

groups

accessRights

subscriptions

discovery

1

n

1

1

1

1

1

1

1

“attribute”



scls

applications

containers

groups

accessRights

subscriptions

discovery

1

n

1

1

1

1

1

1

1

“attribute”



scls

applications

containers

groups

accessRights

subscriptions

discovery

1

n

1

1

1

1

1

1

1

subscriptions

“attribute”



scls

applications

groups

containers

accessRights

subscriptions

discovery



applications

containers

groups

subscriptions

mgmtObjs

“attribute”



subscriptions

“attribute”

m2mPocs

notificationChannels

attachedDevices

accessRights

“attribute”



containers

groups

subscriptions

notificationChannels

accessRights

“attribute”



subscriptions

“attribute”



membersContent

subscriptions

“attribute”

members



subscriptions

“attribute”



subscriptions

subscriptions

“attribute”

containerInstances

“attribute”



latest

oldest

Server

ETSI M2M & 3GPP MTC Applications

3GPP MTC Functionalities

MTC-IWF

GGSN/
P-GW

Core Network
RAN
UE

Application Server
(AS)

MTC UE Application

Gi/SGi

Um/Uu/LTE-Uu

Service Capability Server
(SCS)

1

Application Server
(AS)

2

Gi/SGi

Tsp

1

Indirect Model

Hybrid Model

Direct Model

2

1

2

IP-based End-to-End M2M Software Development Platform
(M2M Device + M2M Gateway + M2M Server)
à Network and application agnostic but aware
à Middleware providing common M2M API
à Enabling horizontal solutions

Configurable Charging

Interworking with Cellular MTC

Device Management

Capillary Network Integration
(ZigBee)

Service Discovery

RESTful Application API

M2M
Gateway Proxy

Security
(Integrity Validation)

Semantic Services

Cloud-based M2M
Server

User 1

Web Interface

Submit SDK Requirement

Return Customized SDK

User 2

Submit SDK Requirement

Return Customized SDK

InterDigital’s
M2M SDP

New SDK
Configuration
Request

New SDK Created

Server





M2M
Server

M2M Area
Network

M2M Service Discovery Server
(DNS/DNS-SD)

Transport
Network





Drag the side handles to change the width of the text block.

URGENT!

Standard M2M
Network

Connectivity

Cognition

Cloud

Collaboration

Context

Content
