1
EdgeLink? Solution
? 2017 InterDigital, Inc. All Rights Reserved.
Transport Network Definition
External Networks
Edge
Transport
High Capacity, Low
Latency, Wired and
Wireless,
Diverse Integrated
Traffic
Internet of
Everything
Small CellRRU
Local Data Center
User Plane
vBBU
Edge Computing
Content Caching
Core
Transport
Optical Transport
Networks Long-Haul
Core Network
Control Plane
NFV
Billing
Orchestration
2 2? 2017 InterDigital, Inc. All Rights Reserved.
EdgeLink? Solution ? mmW 5G Transport
SDN-based Multi-hop Mesh Network composed of
Gigabit, Low-Latency Millimeter Wave Links
? WiGig / 802.11ad baseband
? 60GHz long range, 38dBi gain antennas
? Multi-tenant, multi-service level transport slice management
? Mesh topology for fault tolerance and availability
EdgeLink Nodes:
? Network Discovery and Neighbor Selection
? OpenFlow-based, mmW MAC/PHY/RF
Mesh Controller Software:
? SDN-based, manages the mesh topology to maintain
Transport Slice Service Level requirements
O&M Software
? Cloud-enabled, web-interface for remote operations and
monitoring
InterDigital?s
Cloud-Based
Software Platform
OpenFlow Mesh Controller
WiGig Baseband
RF
WiGig Baseband
RF
. . .
Software
Hardware
INTERDIGITAL MESH LAYER SOFTWARE
Antenna Unit
Network Unit
? 2017 InterDigital, Inc. All Rights Reserved. 3
4
Intelligent Software to Build a Carrier Grade
Edge Network
? EdgeLink? solution is a SDN controlled
multi-hop mesh network of mmWave
transport nodes
? Cluster of EdgeLink nodes connected by
mesh to EdgeLink Gateway
? Key Components
? EdgeLink? solution Nodes
? Network Discovery and Neighbor Selection
? OpenFlow Switch (Open vSwitch)
? mmW MAC/PHY/RF air interface
? Mesh Controller Software
? Built on SDN frameworks (OpenDayLight, ONOS)
? O&M Software
? Web-based interface for remote O&M
? 2017 InterDigital, Inc. All Rights Reserved.
Easily Customizable Software using Flexible Interfaces
Northbound APIs (REST)
Base Network Service
Functions
Service Abstraction Layer EdgeLink? Controller
OpenFlow
6
EdgeLink?
Controller
Gateway Node
IP CLOUD
Non-Gateway
Node
InterDigital?s EdgeLink
Mesh Controller
Software, O&M
EdgeLink Cluster EdgeLink Cluster
Operator 1
Operator 2
5
Mesh Software Functions
? Network discovery and autonomous neighbor
selection
? Proprietary in-band signaling with the Mesh
Network Controller for Topology management
? Management of node and sector state machines
? Link Failure handling and switching to alternate
path
? Sector Recovery and Node Recovery
? Link metric collection
? L2 transport implemented by OpenVSwitch
? SNMP support with EdgeLink? MIB
? Ease of configurability via text file configuration
parameters 2023
802.11ad PHY
Host IF
60GHz Phased Array
Node Manager
and State
Machine
Configuration
Manager
Event Manager
Link Metrics
Scheduling &
QoS Manager
Routing
Manager
Baseband-Host Interface (Adaptation Layer)
Mesh Controller Interface (OpenFlow)
Ethernet Convergence Layer /
Layer 2 Bridge
Ethernet
Virtual Switch (OVS)
Buffer Management
Centralized
Routing
OpenDayLight, ONOS
Neighbor
Selection
QoS
(EIR and CIR Traffic)
Network Metrics
and Status
Mesh Node
Mesh Controller
Gateway
and/or Access
Point
WiGig BB & RF (Sector 1)
802.11ad PHY
Host IF
60GHz Phased Array
WiGig BB & RF (Sector
N)
Ethernet
Internet or
Private Network
? 2017 InterDigital, Inc. All Rights Reserved.
Supports Integrated 5G Transport Networks - Crosshaul
Processing
cloud
Core Backhaul (BH) Fronthaul (FH)
CPRI
CPRI
CPRI
Point-to-point network
Processing
cloud
Crosshaul: Integrated FH/BH
Packet-based network
Core
? Today?s C-RAN mobile transport network will not scale to
support additional spectrum and antennas
? Separated fronthaul and backhaul management adds
complexity and cost
? C-RAN functional splits are fixed and static
? An integrated fronthaul/backhaul (Crosshaul) will support
diverse 5G traffic types
? Unified management built on SDN frameworks
? Wireless and wired transport for dense network edge
connections, with path diversity for high reliability
6? 2017 InterDigital, Inc. All Rights Reserved.
EdgeLink at 5G Berlin Testbed
? EdgeLink? solution deployed into the 5G Berlin
Testbed, hosted by Fraunhofer HHI ? under the 5G
Crosshaul project
? 3 EdgeLink mmW Nodes ? outdoor installation on
buildings within the Fraunhofer and Berlin Technical
University campuses:
? Ranging from 95 to 185 meters distances
? 1 GW + 2 non-GW Nodes
? Multiplexing of Fronthaul and Backhaul traffic over
the InterDigital mmW EdgeLink Mesh transport
network:
? Backhaul == Commercial LTE Small Cell
? Fronthaul == Cloud-RAN (remote radio units and centralized
baseband) provided by Core Network Dynamics, Crosshaul
Partner
? Executed a range of experiments considering traffic loading
profiles under real-world conditions
? 2017 InterDigital, Inc. All Rights Reserved.
Control Plane
EdgeLink? solution Mesh
SDN Controller
EdgeLink? solution EMS
Live EdgeLink ? solution matches 5G Berlin ? Crosshaul Testbed
EdgeLink? Solution ? Live MWC 2017 Demo
EdgeLink? solution Wireless
mmW Crosshaul Transport
Core Network
Cloud RAN
Baseband
Processing Unit
Open EPC
MME
S-GW,
PGW
3D Video Goggles
HD, 3D Camera
Backhaul ? eNodeB
Emulation
Remote Radio Unit
(Next Generation
Fronthaul)
8? 2017 InterDigital, Inc. All Rights Reserved.
